Deublin 1129-036-301 Rotary Union Pop-off M16X1.5LH 18MM

Deublin 1129-036-301 Rotary Union Pop-off M16X1.5LH 18MM

Rotary Union M16x1.5 Left Hand 0.708" Pilot Rotor Connection, and 3/8"-19 PT Housing Connection for Coolant and MQL.

Union pop-off M16X1.5LH 18MM. Single passage for coolant or MQL. Patented pop-off technology allows unlimited dry running without media pressure. Pop-off stroke of 0.7-3.0 mm compensates for thermal expansion of spindle during extended operation as well as variations in drawbar position. Full-flow design has no obstructions to trap chips or debris. Balanced mechanical seals made from silicon carbide for long life even under difficult operating conditions. Anodized aluminum housing resists corrosion.

Additional Description

-Single passage for coolant or MQL

-Pop-Off™ technology allows unlimited dry running without media pressure

-Pop-off stroke of 0.7-3.0 mm compensates for thermal expansion of spindle during extended operation as well as variations in drawbar position

-Full-flow design has no obstructions to trap swarf or debris

-Balanced mechanical seals made from silicon carbide for long life even under difficult operating conditions

-Anodized aluminum housing resists corrosion
