10.01.12.00922 VCSP-U 160x115x16.5 Bottom Rubber Suction Plate

  • • 160x115x16.5mm bottom vacuum plate
  • • Schmalz 10.01.12.00922 lower suction plates
  • • VCSP-U 160x115x16.5
  • • Bottom rubber 160 x 115 mm
  • • Below suction plate for Homag/Weeke/IMA
  • • Dimensions (L x W): 160 x 115 mm
  • • Height H: 16.5 mm
  • • Lower rubber gasket for fixing vacuum block 10.01.12.00949
  • INQUIRY


10.01.12.00922 VCSP-U 160x115x16.5 Bottom Rubber Suction Plate

This bottom suction plate, Schmalz No.: 10.01.12.00922, is the 160 x 115mm replacement below rubber cover for the VCBL-K2 vacuum pod blocks. Work with Homag / Weeke / IMA CNC vacuum blocks with H = 100 mm.

VCBL-K2 bottom cover.jpg

The replacement suction plate for Schmalz vacuum block VCBL-K2 160x115x100 K2 with article number: 10.01.12.00949 and VCBL-K2 125x75x100 Q  Article-No.: 10.01.12.00951.

vacuum block gasket.jpg

VCSP-U 160x115x16.5 lower vacuum suction plate features:
Dimensions (L x W): 160 x 115 mm
Height H: 16.5 mm
For: Vacuum block VCBL-K2, 2-circuit console
Vacuum beam type VCBL-K2
Work with Homag / Weeke / IMA CNC machine
VCSP-U 160x115x16.5.jpg

RicoCNC supplies a range of replacement suction plates and complete vacuum blocks for CNC router processing centers, such as Homag, Weeke, IMA, Biesse Rover, SCM, Morbidelli, Excitech, etc.

lower suction plates.jpg

If any needs of CNC spare parts and woodworking machine parts & tools, welcome your inquiry.
bottom vacuum plate.jpg

bottom rubber pads.jpg

below suction plate.jpg
