Homag 4-086-05-0462 Beckhoff KL1408 Digital Input Terminal 8-Channel Automation Module

Homag 4-086-05-0462 Beckhoff KL1408 Digital Input Terminal 8-Channel Automation Module

• BECKHOFF KL1408
• Beckhoff KL1408 PLC Modules
• Homag 4-086-05-0462 (4086050462)
• 24 V DC Terminal
• Digital input terminal
• 3.0 ms filtertime
• 8 x digital input module KL1408
• Beckhoff Automation KL1408
INQUIRY

Beckhoff Automation KL1408.jpg

Homag 4-086-05-0462 Beckhoff KL1408 Digital Input Terminal 8-Channel Automation Module

The KL1408 digital input terminal acquires the binary 24 V DC control signals from the process level and transmits them, in an electrically isolated form, to the higher-level automation unit. Each Bus Terminal contains eight channels which indicate their signal state by means of light emitting diodes. It is widely used in Homag machines. Homag 4-086-05-0462 (4086050462)
KL1408 PLC.jpg

Special Features:
input specification type 1/3
no bouncing due to mechanical switches thanks to 3 ms input filter
BECKHOFF KL1408.jpg

KL1408 Bus Terminal Technical Data:

Technical data	KL1408
Connection technology	1-wire
Specification	EN 61131-2, type 1/3
Number of inputs	8
Nominal voltage	24 V DC (-15 %/+20 %)
“0” signal voltage	-3…+5 V (EN 61131-2, type 1/3)
“1” signal voltage	11…30 V (EN 61131-2, type 3)
“0” signal current	0…1.5 mA
“1” signal current	2.0…2.5 mA
Input filter	typ. 3.0 ms
Current consumption K-bus	typ. 5 mA
Current consumption power contacts	typ. 2 mA + load
Electrical isolation	500 V (K-bus/field potential)
Bit width in the process image	8 inputs
Configuration	no address or configuration setting
Weight	approx. 55 g
Operating/storage temperature	-25…+60 °C/-40…+85 °C
Relative humidity	95 %, no condensation
Vibration/shock resistance	conforms to EN 60068-2-6/EN 60068-2-27
EMC immunity/emission	conforms to EN 61000-6-2/EN 61000-6-4
Protect. rating/installation pos.	IP20/variable
Pluggable wiring	for all KSxxxx Bus Terminals
Approvals/markings	CE, UL, ATEX, DNV GL
Ex marking	II 3 G Ex nA IIC T4 Gc

KL1408 module.jpg
There are also many other EtherCAT terminals products made from Beckhoff, please send the model number and images, we will check and reply you quickly.
