Double Heads Spindles Heavy Type Wood CNC Router Engraving Machine W1325VH
Product Name:
Double Heads Spindles Heavy Type Wood CNC Router Engraving Machine W1325VH
Number :
W1325VH
:
:

Product Description:

Double Heads Spindles Heavy Type Wood CNC Router Engraving Machine

Double Heads Spindles Heavy Type Wood CNC Router Engraving Machine
Model: W1325VH

This double heads CNC router machine equipped with heavy duty stable vacuum suction table and vacuum pump, double heads engraving at the same time. It enhances the productivity and low down the processing cost. CNC router double heads working together can finish double objects at one time.

CNC Router With Double Head Spindles Features:
1. The heavy type cnc machine adopts steel structure, seamless welding, according to the standard industry to produce. T type heavy duty structure make the cnc machine stable for wood door making.
2. X Y Z axes adopt Taiwan TBI linear square guide rail, high precision and great loading capacity.
3. X and Y axis adopt rack and pinion transmission. Faster working, higher efficiency and low cost. Z axis adopts imported ball screw transmission, high accuracy.
4. High performance subdivision stepper motor operates smoothly at maximum speed.
5. Water cooled spindle 4.5kw, low noise, good for long time mass processing, powerful for solid wood door making. Two heads enhance productivity.
6. Perfect oil lubricating system makes the maintenance more convenient.
7. DSP control system, easy to operate and it has memory for break-point when the electricity power off or the tool is broken. When power comes or new cutters fixed, the cnc wood machine can continue working from the break-point.
8. Compatible CAD/CAM designing software eg: Type3/Artcam/castmate/wentai/UG etc.
9. OEM and customize different kinds of size and configuration to meet customer needs.

Double Heads Wood CNC Router Applications:
This wood cnc machine is suitable for wood door making, 3d wood cutting, aluminium, wood, MDF, acrylic, artificial materials, etc, such as classical furniture, relief, wall bed mechanism, cabinet doors, advertising products, wooden products, computer desk, etc.

Double Head Woodworking CNC Router Parameters:

Description

Parameter

X,Y,Z working area

1300x2500x200mm

X,Y,Z Traveling positioning accuracy

±0.03/300mm

X,Y,Z Repositioning positioning accuracy

±0.03mm

Lathe bed frame

Heavy duty steel square tubes

X,Y Structure

Rack drive, Taiwan HIWIN guide

Z Structure

Taiwan TBI ball screw and Taiwan HIWIN guide

Drive motors

Stepper system

Table surface

Vacuum table

Max power consumption

(without spindle)2.0KW

Max rapid travel rate

30000mm/min

Max working speed

15000mm/min

Spindle power

4.5KW (other power optional)

Spindle speed

0-20000RPM

Spindle inverter

Fuling inverter

Working voltage

AC380V /50/60Hz,3PH

Command language

G Code

Operatiing system

DSP system (Nc studio/Mach3/Syntec optional)

Computer interface

USB

Flash memory

512M(U Disk)

Collet

ER25

X,Y Resolution

<0.02mm

Software compatibility

Type3/ Artcam/ MasterCAM/ Ucancam/ JDpaint etc

Running environment temperature

0-45 centigrade

Relative humidity

30%-75%

Mini order quantity

1 set

Warranty

1 year

Delivery time

15 workdays

Optional parts

1. Rotary axis system
2. Dust collector



Quality Control

1. Strict control of each link of machine assembly, ensure the machine clean and beautiful.
2. 48 hours continuous working before the machine leave the factory, ensure high quality of the machine.



After sales service

1. 24 hour technical support by email, calling or MSN
2. User-friendly English manual and video for machine using and maintaining.
3. Our cnc machines obtain CE and ISO9001 certificate.
