Polycrystalline PCD CNC Router Bits Diamond Tipped Right Hand Rotation Cutting Tools
Product Name:
Polycrystalline PCD CNC Router Bits Diamond Tipped Right Hand Rotation Cutting Tools
Number :
PCD Spiral Router Nesting Tool Bits Z=3+3
:
:

Product Description:

laminated panel cutting PCD router bits

Polycrystalline PCD CNC Router Bits Diamond Tipped Right Hand Rotation Cutting Tools
Model: PCD Spiral Router Nesting Tools Z=3+3

This industrial CNC Polycrystaline Diamond (PCD) router bits is the top of the range PCD tool for CNC nesting. With 3+3 shear cut design feature, this durable cutter ensures a clean finish on both top and bottom surfaces of your work piece. Designed to perform at highest feed rates. Plunge cut facility also.

The router bits are specially designed for industrial CNC applications in a variety of tough, abrasive materials such as particleboard, MDF, veneer, hardwood, plywood and melamine. The bits are ideal for cutting, jointing and rabbeting in these materials.
Our 3-flute diamond bit features a solid carbide tool body and a short upcut and like our 2 flutes it’s suitable for nesting cuts.  The cutting edges shear toward the center of the material in an up/down angle, to provide a very clean cut on laminated materials. This bit can be sharpened 6-8 times when used under normal wear conditions.

PCD Diamond Router Bit Features:
Blade Material: PCD Tipped
PCD Tip Height: 4 mm
Flutes: 3
Tooth Shape: Axial
Tooth Seating: Straight
Cotting Geometry: Positive
Max RPM: 24000
Re-sharpen: 6-8 times
Applicable Machines: NC or CNC router, or fixed head routers with an auto-feed
Applicable Materials: Raw material, melamine and laminated, particle board, MDF, HPL and veneered panels.
Please Note: PCD tool will require extra user care due to its brittle nature.

Polycrystalline Diamond Router Cutters Size:

Item No. RH

CED

CEL

SHK

OVL

Z

H

E010

20

28

20

90

3+3

4

E020

20

37

20

96

3+3

4

E030

20

45

20

105

3+3

4

E040

20

28

25

96

3+3

4

E050

20

37

25

105

3+3

4

E060

20

45

25

105

3+3

4

E070

25

28

25

96

3+3

4

E080

25

37

25

105

3+3

4

E090

25

45

25

113

3+3

4

E100

25

55

25

123

3+3

4



We can also supply you other edm consumables spare parts and cnc spare parts.

Payment can be made by Western Union, Paypal, T/T.

Welcome your inquiry!

PCD tipped tooling router bits and cutters PCD Diamond Router Tools
