Homag 4008610463 4-008-61-0463 Wenglor LN40PA3 Sensor
This sensor is Wenglor Retro-Reflex sensor LN40PA3. It can be used on Homag woodworking machine. The part number is 4008610463 or 4-008-61-0463.
Specification of Wenglor LN40PA3 sensor:
Range | 11,000 mm |
Reference Reflector/Reflector Foil | RQ100BA |
Switching Hysteresis | < 15 % |
Light Source | Red Light |
Polarization Filter | yes |
Service Life (T = +25 °C) | 100,000 h |
Max. Ambient Light | 10,000 Lux |
Opening Angle | 4 ° |
Two-Lens Optic | yes |
Supply Voltage | 10 ... 30 V DC |
Current Consumption (Ub = 24 V) | < 40 mA |
Switching Frequency | 500 Hz |
Response Time | 1 ms |
Temperature Drift | < 10 % |
Temperature Range | -10 ... 60 °C |
Switching Output Voltage Drop | < 2.5 V |
PNP Switching Output/Switching Current | 200 mA |
Residual Current Switching Output | < 50 µA |
Short Circuit Protection | yes |
Reverse Polarity Protection | yes |
Overload Protection | yes |
Protection Class | III |
Setting Method | Potentiometer |
Housing Material | Plastic |
Full Encapsulation | yes |
Degree of Protection | IP67 |
Connection | M12 × 1; 4-pin |
PNP NC, PNP NO | yes |
Housing Material | Plastic |
PNP NC, PNP NO | yes |
Circuit | NC |
RicoCNC can offer a range of electric components for Homag, Biesse, SCM, and other brands of woodworking machines.
If you are looking for woodworking machine accessories, welcome to contact us.
